Panoramic
Camera
|
|
Image Sensor
|
Three 1/2.8"
progressive scan CMOS
|
|
Min. Illumination
|
Color: 0.05 Lux @(F2.0, AGC
ON) B/W: 0.01 Lux @(F2.0, AGC ON)
0 Lux with IR
|
|
Shutter Time
|
50 Hz: 1/25 s to 1/30,000 s
60 Hz: 1/30 s to 1/30,000 s
|
|
Day & Night
|
IR Cut Filter
|
|
Gain
|
Auto/Manual
|
|
WDR
|
Digital WDR
|
|
Smart Image Enhancement
|
HLC / BLC / 3D DNR / Regional
Exposure
|
|
White Balance
|
Auto / Manual / ATW
(Auto-Tracking White Balance) / Indoor / Outdoor / Fluorescent Lamp / Sodium
Lamp
|
|
Privacy Mask
|
4 × 3 programmable privacy
masks
|
|
Focal Length
|
2 mm
|
|
Aperture Range
|
F2.0
|
|
FOV
|
Horizontal field of view:
128.5° × 3 Vertical field of view: 75.7° Diagonal field of view: 144°
|
|
PTZ
Camera
|
|
Image Sensor
|
1 / 2.8" progressive
scan CMOS
|
|
Min. Illumination
|
Color: 0.05 Lux @(F2.0, AGC
ON) B/W: 0.01 Lux @(F2.0, AGC ON)
0 Lux with IR
|
|
Shutter Time
|
50 Hz: 1/25 s to 1/30,000 s
60 Hz: 1/30 s to 1/30,000 s
|
|
Day & Night
|
IR Cut Filter
|
|
Gain
|
Auto / Manual
|
|
WDR
|
Digital WDR
|
|
Smart Image Enhancement
|
HLC / BLC / 3D DNR / Regional
Exposure / Regional Focus
|
|
White Balance
|
Auto / Manual / ATW
(Auto-Tracking White Balance) / Indoor / Outdoor / Fluorescent Lamp / Sodium
Lamp
|
|
Privacy Mask
|
8 programmable privacy
masks
|
|
Digital Zoom
|
8×
|
|
Focus Mode
|
Semi-automatic / Manual
|
|
Focal Length
|
2.8 mm to 12 mm, 4× optical
zoom
|
|
Zoom Speed
|
Approx.5.4 s (optical, wide
- tele)
|
|
FOV
|
Horizontal field of view:
120° to 56.6° (wide - tele)
Vertical field of view:
61.8° to 31.7° (wide - tele)
Diagonal field of view:
149° to 65° (wide - tele)
|
|
Min. Working Distance
|
10 mm to 1500 mm (wide -
tele)
|
|
Aperture Range
|
F2.0 to F2.4
|
|
Pan and Tilt Range
|
Pan: 0° to 350°; Tilt: 0°
to 90°
|
|
Pan and Tilt Speed
|
Pan speed: 0.1° / s to 30°
/ s (configurable), preset speed: 30° / s Tilt speed: 0.1°/s to 30°/s
(configurable), preset speed: 30°/s
|
|
Proportional Zoom
|
Support
|
|
Preset Number
|
300
|
|
Power-off Memory
|
Support
|
|
PTZ Status Display
|
Support
|
|
Preset Freezing
|
Support
|
|
Scheduled Task
|
Preset / Dome Reboot / Dome
Adjust
|
|
Dual-VCA
|
Support
|
|
Smart Event Detection
|
Audio Exception Detection, Intrusion
Detection, Line Crossing Detection
|
|
System
|
|
IR
|
Up to 10 m IR (radius)
|
|
PTZ Linkage
|
Support
|
|
SVC
|
Support
|
|
ROI
|
Main stream and sub-stream
respectively supports eight fixed areas.
|
|
Video Compression
(Sub-stream enabled)
|
Panoramic camera:
Main stream: H.265 / H.264
Sub-stream: H.265 / H.264
H.264 with Main Profile / High
Profile, H.265 with Main Profile PTZ camera:
Main stream: H.265 / H.264
Sub-stream: H.265 / H.264 /
MJPEG
H.264 with Main Profile / High
Profile, H.265 with Main Profile
|
|
Video Compression
(Sub-stream not enabled)
|
Panoramic camera:
Main stream: H.265 / H.264
H.264 with Main Profile / High
Profile, H.265 with Main Profile PTZ camera:
Main stream: H.265 / H.264
/ MJPEG
H.264 with Main Profile / High
Profile, H.265 with Main Profile
|
|
Video Bitrate
|
32 Kbps to 8192 Kbps
|
|
Audio Compression
|
G.711alaw / G.711ulaw / G.722.1
/ G.726 / MP2L2
|
|
Audio Bitrate
|
G.711alaw / G.711ulaw: 64
Kbps
G.722.1 / G.726: 16 Kbps
MP212: 32 Kbps / 64 Kbps / 128
Kbps
|
|
Resolution
(Sub-stream enabled)
|
Panoramic camera: Main
stream:
50 Hz: 20 fps (1920 × 1080,
1280 × 960, 1280 × 720)
60 Hz: 20 fps (1920 × 1080,
1280 × 960, 1280 × 720)
Sub-stream:
50 Hz: 20 fps (704 × 576,
640 × 480, 352 × 288)
60 Hz: 20 fps (704 × 480,
640 × 480, 352 × 240)
PTZ camera: Main stream:
50 Hz: 20 fps (1920 × 1080,
1280 × 960, 1280 × 720)
60 Hz: 20 fps (1920 × 1080,
1280 × 960, 1280 × 720)
Sub-stream:
50 Hz: 20 fps (704 × 576,
640 × 480, 352 × 288)
60 Hz: 20 fps (704 × 480,
640 × 480, 352 × 240)
|
|
Resolution
(Sub- stream not enabled)
|
Panoramic camera: Main
stream:
50 Hz: 25 fps (1920 × 1080,
1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288)
60 Hz: 30 fps (1920 × 1080,
1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)
PTZ camera: Main stream:
50 Hz: 25 fps (1920 × 1080,
1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288)
60 Hz: 30 fps (1920 × 1080,
1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)
|
|
Basic Event Detection
|
Motion Detection, Video
Tampering Detection, Exception
|
|
Network
|
|
Smart Record
|
ANR (Automatic Network
Replenishment)
|
|
Network Storage
|
Built-in memory card slot,
support Micro SD / SDHC / SDXC, up to 256 GB
|
|
Protocols
|
IPv4 / IPv6, HTTP, HTTPS,
802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP,
DHCP, PPPoE, Bonjour
|
|
API
|
Open-ended, support ONVIF,
ISAPI, and CGI, support HIKVISION SDK and Third-Party Management Platform
|
|
Simultaneous Live View
|
Up to 4 × 4 channels
|
