Motion Detection 2.0
|
|
Human/Vehicle
Analysis
|
Deep
learning-based motion detection 2.0 is enabled by default for all analog channels,
it can classify human and vehicle, and extremely reduce false alarms caused by
objects like leaves and lights;
Quick
search by object or event type is supported;
|
|
Perimeter Protection
|
|
Human/Vehicle
Analysis
|
Up to
2-ch
|
|
Facial Detection
|
|
Facial
Detection and Capture
|
Face
picture detection, face picture search
|
|
Recording
|
|
Video
Compression
|
H.265
Pro+ / H.265 Pro / H.265 / H.264+ / H.264
|
|
Encoding
Resolution
|
When
1080p Lite mode is not enabled:
3K lite
/ 5MP lite / 4MP lite / 1080p / 720p;
When
1080p Lite mode is enabled:
3K lite
/ 5 MP lite / 4 MP lite / 1080p lite / 720p lite
|
|
Frame
Rate
|
Main
stream:
When
1080p Lite mode not enabled:
For
3K stream access: 3K lite@12fps;4 MP lite/1080p@15fps;
720p@20fps
For
5 MP stream access: 5MP lite @ 12fps;
4MP lite/1080p @ 15fps; 720p @ 20fps
For
4 MP stream access: 4MP lite / 1080p @15fps; 720p@25fps (P)/30fps (N)
For
1080p stream access: 1080p/720p@15fps;
For
720p stream access: 720p
When
1080p Lite mode enabled:
3K lite
/ 5 MP lite @ 12fps; 4MP lite @ 15fps; 1080p lite / 720p lite @25fps
(P)/30fps (N)
|
|
Video
Bitrate
|
32 Kbps
to 6 Mbps
|
|
Dual-stream
|
Support
|
|
Stream
Type
|
Video,
Video & Audio
|
|
Audio
Compression
|
G.711u
|
|
Audio
Bitrate
|
64 Kbps
|
|
Video and Audio
|
|
IP Video
Input
|
ch (up
to 5-ch）
Up
to 6 MP resolution Enhanced IP mode on:
ch (up
to 6-ch), each up to 4 Mbps
Support
H.265+ / H.265 / H.264+ / H.264 IP cameras
|
|
Analog
Video Input
|
4-ch;BNC
interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
|
|
HDMI
Output
|
1-ch,
1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz,
HDMI/VGA
simultaneous output
|
|
CVBS
Input
|
PAL/NTSC
|
|
CVBS
Output
|
1-ch,
BNC (1.0 Vp-p, 75 Ω),
resolution:
PAL: 704 × 576, NTSC: 704 × 480
|
|
Synchronous
playback
|
4-ch
|
|
HDTVI
Input
|
3K (2960
x 1665) @ 20 fps, 5MP (2560 × 1944)@20 fps, 4MP (2560 × 1440)@30 fps, 4MP (2560
× 1440) @25 fps,1080p @ 30 fps, 1080p @ 25 fps,720p@30 fps, 720p@25 fps
|
|
AHD
Input
|
5 MP
(2560 × 1944) @20 fps,4 MP(2560 × 1440)@30 fps, 4MP(2560 × 1440)@25 fps, 1080p@30
fps, 1080p@25 fps, 720p@30 fps, 720p@25 fps
|
|
VGA
Output
|
1-ch,
1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
|
|
HDCVI
Input
|
5MP
(2592 × 1944) @ 20 fps,4MP (2560 × 1440) @ 30 fps, 4MP (2560 × 1440) @ 25 fps,
1080p@30 fps, 1080p@25 fps, 720p@30 fps, 720p@25 fps
|
|
Audio
Output
|
1-ch,
RCA (Linear, 1 KΩ)
|
|
Audio
Input
|
1-ch,
RCA (2.0 Vp-p, 1 KΩ),4-ch via coaxial cable
|
|
Two-Way
Audio
|
1-ch,
RCA (2.0 Vp-p, 1 KΩ) (using the first audio input)
|
|
Network
|
|
Total
Bandwidth
|
72 Mbps
|
|
Network
Protocol
|
TCP/IP,
PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF
|
|
Remote
Connection
|
32
|
|
Network
Interface
|
1, RJ45
10M/100M self-adaptive Ethernet interface
|
|
Auxiliary Interface
|
|
SATA
|
1 SATA
interface
|
|
Capacity
|
Up to
10 TB capacity for each disk
|
|
Serial
Interface
|
RS-485
(half-duplex)
|
|
USB
Interface
|
2 ×
USB 2.0
|
|
Alarm
In/Out
|
N/A
|
|
General
|
|
Power
Supply
|
12 VDC,
1.5A
|
|
Consumption
|
≤ 18 W
|
|
Working
Temperature
|
-10
°C to +55 °C (+14 °F to +131 °F)
|
|
Working
Humidity
|
10%
to 90%
|
|
Dimension
(W × D × H)
|
315
× 242 × 45 mm (12.4 × 9.5 × 1.8 inch)
|
|
Weight
|
≤ 1.16 kg (2.6 lb)
|
