Motion
Detection 2.0
|
|
Human/Vehicle Analysis
|
Deep learning-based motion
detection 2.0 is enabled by default for all analog channels, it can classify
human and vehicle, and extremely reduce false alarms caused by objects like
leaves and lights;
Quick search by object or
event type is supported
|
|
Perimeter
Protection
|
|
Human/Vehicle Analysis
|
Up to 4-ch
|
|
Recording
|
|
Video compression
|
H.265 Pro+ / H.265 Pro / H.265
/ H.264+ / H.264
|
|
Encoding resolution
|
Main stream:
When 1080p lite mode not
enabled: For 4 MP stream access:
4 MP lite@15 fps; 1080p
lite / 720p / WD1 @25 fps (P)/30 fps (N)
For 3 MP stream access: 3 MP / 1080p / 720p / VGA @15 fps
For 1080p stream access:
1080p/720p@15 fps; VGA / WD1
@25 fps (P)/30 fps (N)
For 720p stream access:
720p / VGA @25 fps (P)/30 fps (N)
When 1080p Lite mode
enabled:
4 MP lite / 3 MP@15 fps;
1080p lite / 720p lite / VGA @25 fps (P)/30 fps (N)
|
|
Sub-stream:
WD1/4CIF@12 fps; CIF@25 fps
(P)/30 fps (N)
|
|
Video bitrate
|
32 Kbps to 6 Mbps
|
|
Dual stream
|
Support
|
|
Stream type
|
Video, Video & Audio
|
|
Audio compression
|
G.711u
|
|
Audio bitrate
|
64 Kbps
|
|
Video
and Audio
|
|
IP video input
|
2-ch (up to 10-ch)
Enhanced IP mode on: 4-ch
(up to 12-ch), each up to 4 Mbps
|
|
Up to 6 MP resolution
|
|
Support H.265+ / H.265 / H.264+
/ H.264 IP cameras
|
|
Analog video input
|
8-ch
|
|
BNC interface (1.0 Vp-p, 75
Ω), supporting coaxitron connection
|
|
HDTVI input
|
3K@20 fps, 4 MP@30 fps, 4
MP@25 fps, 3 MP@18 fps, 1080p30, 1080p@25 fps, 720p@60 fps, 720p@50 fps,
720p@30 fps, 720p@25 fps
*: The 3 MP signal input is
only available for channel 1 of iDS-7204HQHI-M1/S, for channel 1/2 of
iDS-7208HQHI-M1/S, and for channel 1/2/3/4 of iDS- 7216HQHI-M1/S.
|
|
AHD input
|
4 MP@25 fps, 4 MP@30 fps,
1080p@25 fps, 1080p@30 fps, 720p@25 fps, 720p@30 fps
|
|
HDCVI input
|
4 MP@25 fps, 4 MP@30 fps,
1080p@25 fps, 1080p@30 fps, 720p@25 fps, 720p@30 fps
|
|
CVBS input
|
PAL/NTSC
|
|
CVBS output
|
1-ch, BNC (1.0 Vp-p, 75 Ω),
resolution: PAL: 704 × 576,
NTSC: 704 × 480
|
|
HDMI output
|
1-ch, 1920 × 1080/60 Hz,
1280 × 1024/60 Hz, 1280 × 720/60 Hz
|
|
VGA output
|
1-ch, 1920 × 1080/60 Hz,
1280 × 1024/60 Hz, 1280 × 720/60 Hz
|
|
Video output mode
|
HDMI/VGA simultaneous
output
|
|
Audio input
|
1-ch (up to 8-ch is
optional), RCA (2.0 Vp-p, 1 KΩ)
|
|
8-ch via coaxial cable
|
|
Audio output
|
1-ch, RCA (Linear, 1 KΩ)
|
|
Two-way audio
|
1-ch, RCA (2.0 Vp-p, 1 KΩ)
(using the first audio input)
|
|
Synchronous playback
|
8-ch
|
|
Network
|
|
Remote connection
|
64
|
|
Network protocol
|
TCP/IP, PPPoE, DHCP, Hik-Connect,
DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF
|
|
Network interface
|
1, RJ45 10/100/1000 Mbps
self-adaptive Ethernet
interface
|
|
Wi-Fi
|
Connectable to Wi-Fi
network by Wi-Fi dongle through USB interface
|
|
Auxiliary
interface
|
|
SATA
|
1 SATA interface, up to 10
TB capacity for each disk
|
|
Serial interface
|
RS-485 (half-duplex)
|
|
USB interface
|
Front panel: 1 × USB 2.0;
Rear panel: 1 × USB 3.0
|
|
Alarm in/out
|
N/A (optional to support)
|
|
General
|
|
Power supply
|
12 VDC, 2 A
|
|
Consumption (without HDD)
|
≤ 24 W
|
|
Working temperature
|
-10 °C to 55 °C (14 °F to
131 °F)
|
|
Working humidity
|
10% to 90%
|
|
Dimension (W × D × H)
|
315 × 242 × 45 mm (12.4 ×
9.5 × 1.8 inch)
|
|
Weight (without HDD)
|
≤ 1.78 kg (3.9 lb)
|
